GE IS420YDOAS1B
- Precise Control: Delivers precise control with a resolution of 24 bits and a following error of less than 0.01% FS.
- Fast Response: Exhibits a fast response time of less than 1 ms to quickly respond to command changes and load disturbances.
- Wide Speed Range: Supports a wide speed range from 0 rpm to rated speed, enabling smooth and precise motion control.
- Multiple Control Modes: Offers multiple control modes, including position, velocity, torque, and force control, to meet diverse application requirements.
- Advanced Features: Provides advanced features like electronic gearing, feedforward compensation, and trajectory planning for enhanced control performance.
- Rugged Design: Built for harsh industrial environments with an operating temperature range of -40°C to +85°C and an IP65 protection rating.
Product Parameters:
| Parameter | Value |
|---|---|
| Rated Power | 2 kW |
| Continuous Torque | 3.8 Nm |
| Peak Torque | 7.6 Nm |
| Rated Speed | 3000 rpm |
| Maximum Speed | 6000 rpm |
| Supply Voltage | 3-phase AC, 400 V |
| Control Resolution | 24 bits |
| Following Error | < 0.01% FS |
| Response Time | < 1 ms |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -55°C to +125°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Protection Rating | IP65 |
| Dimensions | 230 mm x 165 mm x 65 mm |
| Weight | 3 kg |
