GE IC693ALG222

Absolutely! Here is the information on the GE IC693ALG222 module, including its name, description, parameters, and specifications, all in English:

Product Overview

• Product Name: GE Fanuc IC693ALG222 Analog Input Module
• Manufacturer: GE Fanuc (now part of Emerson Electric)
• Product Description: The IC693ALG222 is a 16-channel analog voltage input module designed for use in GE Fanuc’s Series 90-30 programmable logic controllers (PLCs). It provides a way to interface with analog devices that output a voltage signal.

Key Features and Specifications

• Analog Input Module: Converts analog voltage signals to digital values
• Series 90-30: Part of GE Fanuc’s Series 90-30 PLC product line
• Channels: 16 single-ended or 8 differential input channels (selectable)
• Input Range: 0 to +10V or -10 to +10V (selectable)
• Resolution:*
  • 0 to +10V: 2.5mV per count
  • -10 to +10V: 5mV per count
• Update Rate:*
  • All 16 single-ended channels: 6 milliseconds
  • All 8 differential channels: 3 milliseconds
