GE DS200FCGDH1B

The GE DS200FCGDH1B module is a product of the GE Mark V series of boards, which are mainly used in drive and excitation control systems. It is a gate allocation and status card (FCGD) for control of six-pulse phase-controlled irreversible Bridges.

The main functions of this module are:

Receive the control signal: Receive the control signal from the digital Signal Processing card (DSPC) to control the triggering of the thyristor.
Gate signal distribution: The control signal is distributed to each thyristor of the six-pulse bridge.
State feedback: Receives feedback signals from the thyristor and passes these signals to the DSPC for analysis and diagnosis.
System status monitoring: Provides LED indicators to display basic status information of the system.
Product parameters:

Because the specific parameters of the GE DS200FCGDH1B module may vary by application and configuration, it is difficult to provide a detailed list of parameters here. However, its parameters can usually be understood from the following aspects:

Input signal: Control signal type and voltage range from DSPC.
Output signal: Trigger signal type and parameters assigned to the thyristor.
Feedback signal: Type and parameter of feedback signal from thyristor.
Communication interface: Type of interface to communicate with the DSPC, usually using the VME backplane.
Power requirements: Operating voltage and power consumption of the module.
