FOXBORO 873EC-JIPFGZ-5
Description: The 873EC-JIPFGZ-5 module is A module for Invensys Foxboro I/A Series systems. It can provide 8 analog input channels for converting analog signals to digital signals for use by PLC or other control devices.
Product parameters:
Module type: analog input module
Number of channels: 8 channels
Input type: analog voltage, analog current
Input range:
Voltage: 0-10V, -10V to +10V, 1-5V
Current: 0-20mA, 4-20mA
Resolution: 12 bits
Accuracy: 0.1%
Sampling rate: 1000Hz
Interface: Modbus RTU
Power supply: 24V DC
Specifications:
Size: 100mm x 60mm x 20mm
Weight: 100g
Operating temperature: -25℃~60℃
Storage temperature: -40℃~85℃
Humidity: 5%-95%RH
