FANUC A05B-2601-C312
Product name: FANUC A05B-2601-C312 module
Product Description:
The FANUC A05B-2601-C312 module is an 8-way analog input module for the FANUC 30iA series CNC. The module can be used to collect various industrial signals, such as temperature, pressure, flow, etc.
Product parameters:
Number of inputs: 8
Input type: differential
Input voltage: 0… 10 V
Input current: 0… 22 mA
Input impedance: 100 kΩ
Resolution: 12 bits
Absolute accuracy error: +/ -0.025% full scale
Linearity error: +/- 0.005% full scale
Temperature deviation accuracy: +/- 0.001% full scale /°C
COMMON MODE REJECTION: > 70 dB 60 Hz
Insulation between each channel and bus: 1000 V AC for 60 s
Update time: 20 ms
Fault type: Disconnected
Mark: CE
Local signal indication: 8 leds (green) for channel Open: 8 leds (red) for channel failure:
Required bus current: 120 mA
Power consumption W: 2 W
Specifications:
Dimensions: 96 mm x 96 mm x 9.5 mm
Weight: 0.1kg
Operating temperature: -25°C to +70°C
Storage temperature: -40°C to +85°C
