DO2401 7400209-030
DO2401 7400209-030 Industrial-grade High-density Digital Output Module
Product Description
The DO2401 7400209-030 is a high-performance digital output module designed to convert digital control signals from industrial controllers (PLCs, DCS) into switching actions for field devices such as solenoid valves, contactors, and indicator lights. It provides reliable high-density output capabilities, enabling centralized control of multiple devices in complex industrial systems. This module is widely used in manufacturing automation, material handling, and building management systems, where precise and timely activation of actuators is critical for process synchronization and operational efficiency.
In a packaging machine line, the DO2401 7400209-030 module controls 24 solenoid valves responsible for sealing, cutting, and labeling operations. With an output response time of ≤2ms, it ensures precise timing coordination between processes, reducing packaging errors by 22% and increasing production throughput by 18%. In a smart warehouse’s conveyor system, it activates 16 motor contactors and 8 alarm buzzers, responding to PLC commands within 1.5ms to redirect packages or trigger alerts, which improves sorting accuracy by 25% and reduces manual intervention.
Encased in a rugged metal housing with an IP20 protection rating, the module resists dust and mechanical vibration in industrial environments. It operates stably within a temperature range of -10°C to 65°C and a relative humidity of 5%-95% (non-condensing), with a Mean Time Between Failures (MTBF) of ≥150,000 hours. It supports hot-swapping when integrated with compatible racks, minimizing downtime during maintenance or upgrades.
Product Parameters
- Output Performance Parameters
- Number of Channels: 24 independent digital output channels, divided into 4 groups of 6 channels for flexible load distribution.
- Output Type: Relay output (Form A – normally open) with a maximum switching voltage of AC 250V and DC 30V.
- Current Rating: 2A per channel (resistive load), 1A per ch
