DELTA TAU ACC-51E
Product name: DELTA TAU AC-51E module
Product Description:
The DELTA TAU AC-51E module is a 4-way analog output module for Delta Tau Turbo UMAC or MACRO station controllers. The module can be used to output various industrial signals, such as temperature, pressure, flow, etc.
Product parameters:
Output quantity: 4 channels
Output type: differential
Output voltage: 0… 10 V, 0… 5 V, ±10 V, ±5 V
Output current: ±20 mA
Output impedance: 250Ω
Resolution: 16 bits
Absolute accuracy error: +/ -0.025% full scale
Linearity error: +/- 0.005% full scale
Temperature deviation accuracy: +/- 0.001% full scale /°C
COMMON MODE REJECTION: > 70 dB 60 Hz
Insulation between each channel and bus: 1000 V AC for 60 s
Update time: 20 ms
Fault type: line break, short circuit
Mark: CE
Local signal indication: 4 leds (green) for channel Open: 4 leds (red) for channel failure:
Required bus current: 120 mA
Power consumption W: 2.4W
Specifications:
Dimensions: 102.3mm x 203.2mm x 9.5mm
Weight: 0.2kg
Operating temperature: -40°C to +70°C
Storage temperature: -40°C to +85°C
** Application Scenario:
Industrial automation
Process control
Mechanical control
