CPS-150F YASKAWA
The CPS-150F is a power supply module manufactured by YASKAWA, a leading global supplier of motion control and robotics solutions. This power supply is designed to provide reliable and efficient power to YASKAWA’s servo amplifiers and servo motors.
One of the key features of the CPS-150F is its compact size. Measuring just 85mm x 170mm x 125mm, this power supply can be easily integrated into a variety of systems. Despite its small size, the CPS-150F is capable of delivering up to 15A of current at 24V DC.
In addition to its compact size and high current output, the CPS-150F also includes a number of safety features. These include overvoltage protection, undervoltage protection, and overcurrent protection. These safety features help to protect the connected equipment from damage in the event of a power surge or other electrical issue.
The CPS-150F also includes a number of parameters that can be adjusted to suit the specific needs of the connected equipment. These parameters include:
- Output voltage: The output voltage of the CPS-150F can be adjusted from 22V to 26V DC.
- Overvoltage protection level: The overvoltage protection level can be set between 26V and 30V DC.
- Undervoltage protection level: The undervoltage protection level can be set between 18V and 22V DC.
- Overcurrent protection level: The overcurrent protection level can be set between 110% and 140% of the rated current.
GENERAL ELECTRIC DS3800NSCD1B1C BOARD DS3800NSCD
WHEDCO SERVO DRIVE CMC-2070-1-B 78004084
General Electric DS3820CI2AE21C Current Isolator
GE FANUC IC3600ADNA1 PC BOARD IC3600ADNA1
REMANUFACTURED GENERAL ELECTRIC 44A294521-G01 PC BOARD 44A294521G01
Mechanical Specifications
- Dimensions: 160 x 97 x 39 mm
- Weight: 0.7 kg
- Cooling: Fanless Design
- Mounting: DIN Rail
Other Features
- LED Status Indicators
- Adjustable Output Voltage
- Conformal Coating for Harsh Environments
- UL, cUL, CE, and TUV Certified
In summary, the YASKAWA CPS-150F power supply is a reliable and versatile option for many industrial applications. Its high efficiency, protection features, and environmental specifications make it an excellent choice for a wide range of applications.
