Pepperl + Fuchs RDC2 module
Product name
Pepperl + Fuchs RDC2 safety relay module

Product description
The Pepperl + Fuchs RDC2 module is a safety relay module for the control and monitoring of safety circuits in safety instrumentation systems (SIS). The module has the following features:

High reliability
High security
Easy to use
Product parameter

Model: RDC2
Operating voltage range: DC 24V
Operating temperature range: -20 to 60°C
Response time: <10ms
Safety level: SIL 3/PLe
Input signal: 2 PNP or NPN security inputs
Output signal: 2 PNP or NPN security output
Product function
Realize the control and monitoring of the safety loop
Ensure the safety of personnel and equipment
Installation instructions
Install the RDC2 module on the appropriate guide rail.
Connect the security input signal to the input terminal of the module.
Connect the security output signal to the output terminal of the module.
Connect the power cable to the power terminal of the module.
Precautions for use
Please read the instructions carefully before use.
Do not use the module in excess of rated voltage and current.
Do not use the module in a humid or dusty environment.
Check the module regularly to make sure it is working properly.
troubleshooting
If the RDC2 module is faulty, refer to the following troubleshooting methods:

Problem: The module is not working properly.

Cause: The power supply voltage is too low or the module is damaged.

Solution: Check the power supply voltage or replace the module.

Problem: The module cannot output a security signal.
