Bently 330500-02-CN

Description: ** The Bently 330500-02-CN module is a 1-channel vibration speed sensor from Bently Nevada for industrial automation applications. It can measure the vibration speed of the machine.

Product parameters:

Sensitivity: 3.94mV/mm/s (100 mV/in/s) ±5%
Frequency response: 4.5 Hz to 5 kHz (270 cpm to 300 kcpm) ±3.0 dB
Maximum cable length: 305 m (1000 ft) of cable
Operating temperature range: -55°C to 121°C

Weight: About 142g
Diameter: 25.3mm
Height: 63.2mm
Case material: 316L stainless steel
Specifications:

Operating temperature: -55°C to 121°C
Storage ambient temperature: -40°C to 85°C

Relative humidity: 95% non-condensing
Working altitude: <= 5000 m
