Bentley 3500/42M
The Bently Nevada 3500/42M module is a four-channel vibration monitoring module for the Series 3500 mechanical monitoring system produced by Bently Nevada, Inc. to monitor the vibration status of rotating machinery and provide fault diagnosis functions. The module has the following features:
Four-channel vibration monitoring
Support for multiple sensors
High precision, high resolution
Fast response
Easy to install and use
Product parameters:
Number of channels: 4
Input type: Voltage, current, IEPE
Input range:
Voltage: ±10V, ±5V, ±1V
Current: ±20mA, ±10mA, ±4mA
IEPE: 10mV/g to 10V/g
Resolution: 16 bits
Accuracy: ±0.05%
Sampling rate: 1ms to 10kHz
Operating temperature: -40°C to +85°C
Dimensions: 233.4 x 160 x 40 mm
Specifications:
Interface: 20-pin connector
Backplane: VME64
