Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 22B-D010N104 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Type | Variable Frequency AC Drive (VFD) |
| Series | PowerFlex 40 |
| Input Voltage | 380-480V AC, 3-Phase (Range: 342-528V) |
| Input Frequency | 50/60 Hz |
| Rated Output Current | 10.5 A |
| Rated Power | 4.0 kW (5.0 HP) |
| Output Voltage | 0-460V AC, 3-Phase |
| Output Frequency | 0-400 Hz (Programmable) |
| Frame Size | B |
| Enclosure Rating | IP20, NEMA/UL Type Open (Panel Mount) |
| Control Method | Sensorless Vector Control & V/Hz |
| Communication Port | Built-in RS-485 (DSI Protocol) |
| Keypad Type | Integral Fixed LED Keypad |
| Dimensions (H×W×D) | 180 x 100 x 136 mm |
| Weight | Approx. 2.22 kg (4.9 lbs) |
| Filter | Without CE Compliant Filter |
| Overload Capacity | 150% for 1 Minute, 200% for 3 Seconds |
Main Features and Advantages
The Allen-Bradley 22B-D010N104 excels in delivering superior motor control performance through its sensorless vector control technology. This advanced control method enables the drive to provide high starting torque and precise speed regulation with 1% accuracy across an 80:1 speed range, thanks to integrated slip compensation and auto-boost features . This capability is particularly beneficial in applications requiring smooth acceleration, load adaptability, and consistent torque at low speeds, eliminating the need for costly and complex encoder feedback systems .
Designed with user-friendliness in mind, the Allen-Bradley 22B-D010N104 features a straightforward programming structure and an intuitive integral LED keypad. The keypad provides out-of-the-box operation using a local potentiometer and control keys, and a Basic Program Group containing the 10 most common application parameters allows for rapid configuration and commissioning . Installation flexibility is another key advantage, as the Allen-Bradley 22B-D010N104 is available in a B Frame size that supports both standard panel mounting and convenient DIN rail mounting, saving valuable panel space . Furthermore, the drive’s ability to be “Zero Stacked” at ambient temperatures up to 40°C offers significant space savings in multi-drive configurations .
The Allen-Bradley 22B-D010N104 is built to meet the demands of various applications, featuring an integral RS-485 communication port that enables simple networking and connection to PC-based programming tools for monitoring, troubleshooting, and configuration . The drive also includes a built-in process PID controller, eliminating the need for external control hardware for many applications . Combined with its robust protective functions against overload, overcurrent, and ground faults, the 22B-D010N104 is a reliable and versatile solution for enhancing the performance and efficiency of industrial machinery .
