ABB S202-D10 2CDS252001R0101

Product name: ABB S202-D10 2CDS252001R0101 module

Product Description:

One 24V DC circuit breaker module for ABB System pro M compact series controllers
With 1 circuit breaker, it can be used to protect motors, valves, etc
Product parameters:

Rated voltage: 24V DC
Rated current: 10A
Rated current tolerance: 125%
Rated short circuit current: 25kA
Operating temperature range: -25°C to +70°C
Storage temperature range: -40°C to +85°C
Specifications:

Dimensions: 72 x 27 x 75mm
Weight: 0.1kg
Connection mode: DIN connection
Protection class: IP65
Applications:

Motor protection
Valve protection
Other applications requiring 24V DC circuit breakers
Advantages:

Protect motors and valves from overcurrent and short circuit damage
Work stable and reliable
Wide operating temperature range
Wiring mode standard
How to use:

Install the S202-D10 module on the DIN rail.

Connect the power supply to the input end of the module.
