ABB REF610C11LCLR

Description: The REF610C11LCLR module is a frequency relay module manufactured by ABB, which is used to measure the frequency of the AC power grid and output switching signals. It has high precision, high reliability and high cost performance, and can be widely used in industrial control, power system, new energy and other fields.

Product parameters:

Model: REF610C11LCLR

Measuring range: 45-65Hz
Accuracy: ±0.05Hz
Set value range: 45-65Hz
Repeatability: ±0.02Hz
Response time: 100ms
Output signal: 1 relay contact
Power supply voltage: 24-240V AC/DC
Operating temperature: -20°C – 70°C
Storage temperature: -40°C – 85°C
Installation method: 35mm guide rail installation
Specifications:

Dimensions: 22.5mm x 45mm x 110mm
Weight: 0.2kg
Features:

Measure the frequency of the AC grid
Compare the measured value with the set value
Output switching signal
With over voltage protection, under voltage protection, short circuit protection and other functions
Applications:

Industrial control
Electric power system
New energy
Pumping station
Air blower
compressor
