ABB PM904F 3BDH001002R0001
The ABB PM904F 3BDH001002R0001 module is a 16-channel digital input module belonging to the ABB PM900 series module. The module provides 16 digital input channels, which can be used to collect switching signals, such as buttons, travel switches, etc.
Product parameter
Main parameter
Module type: digital input module
Number of channels: 16
Input type: switch quantity
Input voltage range: 24VDC
Input current: 2mA
Filtering: Software filtering
Indicator: Power indicator, input status indicator
Installation mode: VMEbus slot
Other parameters
Module size: 160mm x 233mm x 25mm
Weight: 0.5kg
Power consumption: 2W
Ambient temperature: 0 ° C ~ +55 ° C
Storage temperature: -40℃ ~ +85℃
Relative humidity: 5% ~ 95% (no condensation)
specification
Input specification
Rated current: 2mA
Rated voltage: 24VDC
Allowable voltage range: 0.85 ~ 1.15 rated voltage
