ABB PM802F

The ABB PM802F module is an 8-channel analog output module designed for the AC800M series programmable logic controllers (PLCS). The module can be used to convert digital signals from PLCS into analog voltage or current signals in order to control external devices such as valves, motors, etc.

ABB PM802F module has the following features:

Eight channels: Controls eight external devices simultaneously

Supports multiple output types: voltage, current

Wide range: can meet different application requirements
High precision: Ensure the accuracy of the control signal
Programmable filter: eliminates high frequency noise
Fault diagnosis: Detects module faults
Product parameter
Parameter value
Number of channels 8
Output Type Voltage, current
Output voltage range 0-10 V, 0-20 V, 0-50 V
Output current range 0-20 mA, 4-20 mA
Resolution 16 bit
Update rate 256 Hz
Filter programmable
Power supply 24 VDC
