ABB PM511V16 3BSE011181R1
The ABB PM511V16 3BSE011181R1 is a high – performance processor module that plays a crucial role in industrial automation systems. It is designed to handle complex control tasks and data processing requirements efficiently. This module is part of ABB’s product portfolio for industrial control, specifically associated with the AC 400 control system and Advant OCS with Master SW.
It comes equipped with a 25 MHz 68040 processor, enabling it to execute control algorithms and manage data flow in real – time. The module features 16 Mbyte dynamic RAM with ECC (Error – Correcting Code), which significantly enhances data integrity. This is especially important in industrial settings where accurate data handling is essential for reliable operation. Additionally, it has a PCMCIA slot for flash memory card, allowing for flexible data storage and expansion, with a maximum supported flash memory card capacity of 64 MB of type II.
In terms of communication, the PM511V16 offers multiple interfaces. It has an RS – 232 port and an RS – 485 port, which are commonly used for serial communication with other devices such as sensors, actuators, or other controllers. Moreover, it is equipped with an Ethernet port (1 x 10/100 Base – T), facilitating high – speed data transfer and network connectivity. This enables seamless integration with other components in an industrial network, allowing for easy communication and coordination within the overall control system.
The module is designed to operate under a wide range of environmental conditions. It can function in an operating temperature range of – 20 °C to + 60 °C, making it suitable for various industrial environments, including those with extreme temperatures. It is also compliant with CE, UL, and RoHS standards, ensuring its quality, safety, and environmental friendliness.
Product Parameters
- Processor: 25 MHz 68040.
- Memory: 16 Mbyte dynamic RAM with ECC.
- Power Supply:
- Input Voltage: 24 VDC.
- Power Consumption: 5W.
- Communication Interfaces:
- RS – 232 Port: 1.
- RS – 485 Port: 1.
- Ethernet Port: 1 x 10/100 Base – T.
- Storage: PCMCIA slot for type II flash memory card (max capacity 64 MB).
- Operating Temperature Range: – 20 °C to + 60 °C.
Product Specifications
- Product ID: 3BSE011181R1.
- ABB Type Designation: PM511V16.
- Dimensions:
- Net Depth/Length: 274.5 mm.
- Net Height: 27 mm.
- Net Width: 270 mm.
- Weight: 0.8 kg.
- Environmental:
- RoHS Status: Complies with EU directive 2011/65/EU.
- WEEE Category: 5. Small equipment (no external dimension more than 50 cm).
