ABB HPC800K02
The ABB HPC800K02 module is an 8-channel analog output module belonging to the ABB HPC800 series module. The module provides 8 analog output channels, which can be used to output voltage or current signals, control inverter, servo motor and other equipment.
Product parameter
Main parameter
Module type: analog output module
Number of channels: 8
Output type: voltage, current
Output range:
Voltage: 0-10V, 0-20V, ±10V, ±20V
Current: 0-20mA, 4-20mA
Resolution: 12 bits
Accuracy: 0.1%
Update rate: 1000Hz
Isolation: channel to channel, channel to ground
Mounting method: DIN rail mounting
Other parameters
Module size: 115mm x 87mm x 25mm
Weight: 0.3kg
Power consumption: 1.2W
