ABB GD9924BE/V2

The ABB GD9924BE/V2 module is a dual-channel isolated analog input module for converting analog signals to digital signals for use by ABB’s CompactRIO controllers. It has the characteristics of high precision, high reliability and low noise.

Product parameter
Input voltage range: ±10V, ±20V, ±50V, ±100V

Input impedance: 10MΩ
Resolution: 16 bits
Accuracy: ±0.05%

Sampling rate: 500kS/s
Channel isolation: 2500Vrms
Operating temperature: -40℃ ~ 70℃
Storage temperature: -55℃ ~ 85℃
Relative humidity: 5% ~ 95%
Overall dimensions: 110mm x 70mm x 40mm
Weight: 0.2kg
Product characteristics
High accuracy: 16-bit resolution, ±0.05% accuracy
High reliability: isolation design, strong anti-interference ability
Low noise: Low noise design, improve the measurement accuracy
