ABB DSDP140B 57160001-ACX
The ABB DSDP140B 57160001-ACX module is a high-speed counter module for ABB’s Quantum series programmable logic controller (PLC), which is used to measure the frequency, pulse width and time interval of pulse signals. The module has the characteristics of high precision, high reliability, easy to use, etc., and is suitable for various industrial control occasions.
Product parameters:
Number of channels: 2
Count type: rising edge count, falling edge count, double edge count
Counting frequency: up to 20MHz
Pulse width measurement range: 0.1μs to 100ms
Time interval measurement range: 0.1μs to 100ms
Resolution: 1ns
Accuracy: ±0.01%
Power consumption: 5W
Operating temperature: -40°C to +70°C
Storage temperature: -40°C to +85°C
Dimensions: 176 x 64 x 40 mm
Weight: 0.25kg
