ABB CMA136 3DDE300416

Product name

ABB CMA136 3DDE300416 module

Product description

The ABB CMA136 3DDE300416 module is an analog input/output module for the ABB AC800M control system. It can provide the following functions:

Provides 16 analog input channels for receiving analog signals.
Provides 16 analog output channels for the output of analog signals.
Provides extensive diagnostic functions to help you quickly locate faults.
Product parameter

Power supply voltage: 24 VDC
Current consumption: ≤ 100 mA
Analog signal type: voltage, current, frequency, pulse
Analog signal range: 0-10 V, 0-20 mA, 4-20 mA
Resolution: 12 bits
specification

Dimensions: 120mm x 96mm x 76mm
Weight: 0.5kg

Apply

The ABB CMA136 3DDE300416 module can be used for a variety of applications, including:

Control motor, valve and other equipment.
Implement data communication between the controller and external devices.
Expand the functions of the controller.
Main function

Analog input:
Provides 16 analog input channels for receiving analog signals.
Supports a variety of analog signal types, including voltage, current, frequency, pulse, etc.
Resolution: 12 bits
Analog output:
Provides 16 analog output channels for the output of analog signals.
Supports a variety of analog signal types, including voltage, current, frequency, pulse, etc.
Resolution: 12 bits
