ABB CI867K01

The ABB CI867K01 module is a redundant module produced by ABB for the AC800M control system. This module can provide redundancy function and improve system reliability.

Product parameter

Module type: Redundant module
Applicable system: AC800M control system

Redundancy Type: 1:1 redundancy
Communication interface: MODBUS TCP
Transmission speed: 10/100 Mbit/s (Ch1), 10 Mbit/s (Ch2)
Hot swap: Supported
Connector: RJ-45 female head (8 pins)
specification

Dimensions: 60 mm x 100 mm x 22 mm
Weight: About 0.2kg
Ambient temperature: 0°C to +55°C
Storage temperature: -40°C to +70°C
Protection level: IP20
Corrosion protection: complies with G3
Electromagnetic compatibility and CE marking: comply with EMC Directive 2004/108/EC
Electromagnetic radiation: EMC test according to EN 61000-6-4
Electromagnetic immunity: EMC test according to EN 61000-6-2
Electrical safety: UL508, IEC/EN 61131-2
Hazard Classification Site: UL/CSA 60079-15
