ABB CI854A 3BSE030221R1
Product Name
ABB CI854A 3BSE030221R1 PROFIBUS – DP/V1 Interface Module
Product Description
The ABB CI854A 3BSE030221R1 is a PROFIBUS – DP/V1 interface module. It is utilized to connect PROFIBUS – DP slave devices to an AC 800M controller. This module supports up to 124 slave devices on a single segment and has a maximum data rate of 12 Mbit/s. It is equipped with two PROFIBUS DP ports, which can be used to connect up to 32 PROFIBUS devices. Additionally, it features an integrated power supply, which can be used to power the PROFIBUS devices. The CI854A is a versatile and reliable PROFIBUS interface module that is suitable for a wide variety of industrial applications, including process control, factory automation, and building automation systems4.
Product Parameters
- Power Supply: Rated control circuit power voltage \(U_S\): 18 V DC – 30 V DC (including all tolerances, including residual voltage), 24 V DC (A1/A2). Rated control power current \(I_S\): typically 110 mA1.
- Input Characteristics: Input type is digital, HTL – type. There are 10 双通道 inputs (up to SIL 3) and 20 单通道 inputs (up to SIL 2). Input voltage range for “0” signal is 0 V DC – 5 V DC (for safe shutdown), and for “1” signal is 11 V DC – 30 V DC1.
- Output Characteristics
