ABB ACU-01B

ABB ACU-01B module is an analog expansion module belonging to the ABB ACU-01 series module. The module provides 8 analog input channels that can be used to collect voltage or current signals. It has high precision, high stability and rich functional characteristics, and can meet the needs of various industrial control applications.

Product parameter

Main parameter

Module type: analog expansion module
Number of channels: 8
Input type: voltage, current
Input range:
Voltage: 0-10V, 0-20V, ±10V, ±20V
Current: 0-20mA, 4-20mA
Resolution: 12 bits
Accuracy: 0.1%
Update rate: 1000Hz
Isolation: channel to channel, channel to ground
Mounting method: DIN rail mounting
Other parameters

Module size: 115mm x 87mm x 25mm
Weight: 0.3kg
Power consumption: 1.2W
Ambient temperature: -20℃ ~ +60℃
Storage temperature: -40℃ ~ +85℃
