ABB 3HAC17484-9/02

The ABB 3HAC17484-9/02 Universal Digital input module is a 32-channel digital input module for ABB AC500 series control systems. It can be used to monitor the status of various industrial equipment, such as switches, sensors, indicators, etc.

Product parameters:

Number of input channels: 32
Input type: numeric input
Sampling rate: 100 kHz
Resolution: 16 bits
Trigger mode: software trigger, hardware trigger
Memory: 128 KB

Interface: Ethernet
Operating temperature: 0°C to 60°C
Storage temperature: -40°C to 85°C

Relative humidity: 5% to 95% (non-condensing)
Dimensions: 22.5 x 100 x 45 mm
Weight: 0.25kg
Specifications:

Supports a variety of digital input protocols, including TTL, LVDS, RS-422/485, etc
On-board FPGas can be used for custom logic
Support Proficy Machine Edition software for programming
Applications:

Industrial automation
Process control
Machine control
Building automation
Power station
Other applications requiring generic numeric input
Related links:

ABB Product page: [Invalid URL removed]
ABB Manual: [Invalid URL removed]
Photos:

3HAC17484-9/02: [Invalid URL removed]

Chinese translation:

Product name: ABB 3HAC17484-9/02 Universal digital input module

Product Description:

The ABB 3HAC17484-9/02 Universal Digital input module is a 32-channel digital input module for ABB AC500 series control systems. It can be used to monitor the status of various industrial equipment, such as switches, sensors, indicators, etc.
