ABB 3BHE035301R1002

The ABB 3BHE035301R1002 module is a servo controller module produced by ABB, which is suitable for the ACS800 series inverter. This module can provide the following functions:

Control motor speed, torque, position, etc
Provides a variety of protection functions, such as over current, over voltage, over heat, etc

Supports a variety of communication modes, such as RS-485, CANopen, EtherCAT, etc
Product parameter
Parameter value
Model 3BHE035301R1002
Voltage range 380V-480V AC

Current range 2A-100A
Power range 0.75kW-75kW
Control mode Vector control
Protection function overcurrent, overvoltage, overheating, etc
Communication mode RS-485, CANopen, EtherCAT, etc
Operating temperature range 0°C to 60°C
Weight 1kg
specification
Specification and size
Height 127mm
Width 89mm
Depth 152mm
