AB 1769-L36ERM

The AB 1769-L36ERM module is a 3-axis motion control module from Rockwell Automation for the CompactLogix 5370 series controllers. The module can control 3 servo motors or stepper motors for precise motion control.

Product parameter
Number of axes: 3
Control type: servo motor, stepper motor

Position resolution: 16 bits
Speed resolution: 16 bits
Acceleration resolution: 16 bits
Pulse output frequency: 10MHz

Dimensions: 120 x 70 x 80 mm
Weight: 0.3kg
specification
shaft

Quantity: 3
Control type: servo motor, stepper motor
Controls

Position resolution: 16 bits
Speed resolution: 16 bits
Acceleration resolution: 16 bits
Pulse output frequency: 10MHz
