AB 1769-IF8

The AB 1769-IF8 is an isolated input/output module in the MicroLogix 1500 series programmable logic controllers (PLCS) from Rockwell Automation. It supports 8 isolated input channels and 8 isolated output channels and can be used to connect various sensors and actuators. The module has the following features:

Each input channel supports multiple signal types, including DC voltage, current, temperature, and pressure
Each output channel supports multiple signal types, including DC voltage, current, and relay
High isolation between input/output channels prevents ground faults
The module has surge suppression to protect the equipment from electrical interference
Product parameters:

Input type: DC voltage, current, temperature, pressure

Input range: Depends on the input type
Input accuracy: ±0.1% full scale
Input impedance: 22 kΩ (voltage) or 250 Ω (current)
Output type: DC voltage, current, relay
Output current: 0.5A/ channel

Output voltage: 24V DC
