AB 1326AS-B690E-21
The Rockwell Automation Allen-Bradley 1326AS-B690E-21 Discrete I/O module is an extension module for the CompactLogix 5000 PLC system. It can provide additional discrete I/O channels for PLC systems to control external devices.
Product parameters:
Input channels: 16
Number of output channels: 16
Input type: PNP or NPN
Output type: Relay
Input voltage range: 12-24VDC
Output voltage range: 24VDC
Filtering time: 1ms
Operating temperature: -20°C to +70°C
Storage temperature: -40°C to +85°C
Relative humidity: 5% to 95% (non-condensing)
Enclosure protection class: IP20
Weight: 0.2kg
Specifications:
Dimensions: 22.5 x 100 x 45 mm
Mounting method: DIN rail
Applications:
Industrial automation
Process control
Machine control
