A-B MPL-B580F-MJ72AA

The A-B MPL-B580F-MJ72AA module is A Flex I/O module for the ControlLogix®5000 series controllers. It can provide 8 universal analog input channels and 8 universal analog output channels.

Product parameter
Input channel:

Type: Universal analog input
Quantity: 8

Voltage range: ±10V, ±20V, ±50V, ±100V
Current range: ±20mA, ±40mA, ±100mA
Accuracy: 0.05%
Resolution: 16 bits
Sampling rate: 1000Hz
Output channel:
Type: General purpose analog output
Quantity: 8
Voltage range: 0-10V, 0-20V, 0-50V, 0-100V
Current range: 0-20mA, 0-40mA, 0-100mA
Accuracy: 0.05%
Resolution: 16 bits
Isolation: 3000Vrms
Operating temperature: -40℃~+85℃
Storage temperature: -55℃~+125℃
Weight: 0.5kg
specification
Dimensions: 176mm x 114mm x 25mm
Installation method: guide rail installation
