A-B MPL-B540K-SJ24AA

The A-B MPL-B540K-SJ24AA module is one of the Flex I/O modules produced by Rockwell Automation. It is an 8-channel analog input module that converts analog signals into digital signals so that the PLC system can process them. The module has the following features:

High precision: 16 bit resolution

High sampling rate: up to 1000 Hz
Wide range: ±10 V, ±20 V, ±50 V, ±100 V
Multiple filtering options: eliminates signal noise

Fault diagnosis: Detects module faults
Product parameter

Input channels: 8
Resolution: 16 bits
Sampling rate: Up to 1000 Hz
Range: ±10 V, ±20 V, ±50 V, ±100 V
Filter options: 50 Hz, 60 Hz, 100 Hz, 200 Hz, 500 Hz, 1000 Hz
Fault diagnosis: detects module faults
specification

Dimensions: 22.5mm x 100 mm x 125 mm
Weight: 0.5kg
Operating temperature: 0°C to 60°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95% (non-condensing)
