A-B 1336F-CWF50-AN-EN

The A-B 1336F-CWF50-AN-EN module is A wireless local Area Network (WLAN) adapter module in the Allen-Bradley 1336F series module for connecting the ControlLogix 5570 controller to a wireless LAN. The module has the following features:

Support IEEE 802.11a/b/g/n/ac standard
Support 2.4GHz and 5GHz bands

Supports the WPA2-Enterprise security protocol
Have diagnostic function

Easy to use
Product parameter
Model: A-B 1336F-CWF50-AN-EN
Network connection: RP-SMA antenna interface
Communication speed: up to 1300Mbps
Protocol: IEEE 802.11a/b/g/n/ac, WPA2-Enterprise
Rated voltage: 24V DC
Power consumption: <5W
Size: 80mm x 45mm x 25mm
Weight: 0.2kg
Product function
Connect the ControlLogix 5570 controller to the wireless LAN
Realize remote access and control of controller
Installation instructions
Mount the A-B 1336F-CWF50-AN-EN module on the 1336F I/O rack.
Connect the antenna to the RP-SMA antenna interface of the module.
Connect the power cable to the power terminal of the module.
Precautions for use
Please read the instructions carefully before use.
Do not use the module in excess of rated voltage and current.
Do not use the module in a humid or dusty environment.
