The NU8976A99 features a high – performance analog – to – digital converter (ADC) with multiple input channels, allowing simultaneous measurement of multiple signals. It also incorporates advanced digital signal processing (DSP) algorithms, which can filter noise, extract meaningful information, and perform complex mathematical operations on the acquired data. The module is designed to interface seamlessly with other components in a system, such as microcontrollers, field – programmable gate arrays (FPGAs), and computers, enabling efficient data transfer and system integration.
Product Parameters
- Electrical Parameters
- Power Supply: Operates on a dual – power supply configuration of ±15V DC, providing stable power for both analog and digital circuits. This ensures accurate signal acquisition and processing.
- Power Consumption: The module consumes approximately 8W of power under normal operating conditions, making it energy – efficient while maintaining high performance.
- Data Acquisition Parameters
- Number of Input Channels: Equipped with 8 differential input channels, allowing simultaneous measurement of multiple signals. This makes it suitable for applications requiring multi – channel data acquisition, such as multi – sensor monitoring systems.
- Sampling Rate: Capable of achieving a maximum sampling rate of 10 MSPS (Mega Samples Per Second) per channel, enabling high – speed data acquisition. This is essential for capturing fast – changing signals accurately.
- Resolution: Offers a 16 – bit resolution, providing high – precision measurement of analog signals. This high resolution allows for the detection of small signal changes, ensuring accurate data representation.
- Input Voltage Range: The input voltage range can be configured to ±10V, ±5V, or ±2.5V, providing flexibility to accommodate different signal levels. This makes the module adaptable to a wide range of applications.
- Signal Processing Parameters
- DSP Performance: Features a high – performance DSP with a clock speed of 400 MHz, enabling real – time signal processing. This allows for complex algorithms to be executed quickly, ensuring timely analysis of the acquired data.
- Filtering Capabilities: Supports various digital filtering options, including low – pass, high – pass, band – pass, and notch filters. These filters can be configured to remove unwanted noise and interference from the signals, improving the quality of the processed data.
- FFT Resolution: Capable of performing Fast Fourier Transform (FFT) with a resolution of up to 8192 points, enabling detailed frequency analysis of the signals. This is useful for applications such as spectral analysis and vibration monitoring.
- Environmental Parameters
- Operating Temperature Range: Can function reliably within a temperature range of – 20°C to + 70°C, making it suitable for use in various industrial environments, from relatively cold storage areas to warm production facilities.
- Relative Humidity: Withstands a relative humidity of 5% – 95% non – condensing, ensuring stable performance in humid conditions, such as those found in some industrial workshops or near water – based processes.
Product Specifications
Physical Specifications
- Dimensions: Compact in size, with approximate dimensions of 150mm (length) × 100mm (width) × 30mm (height), facilitating installation in standard industrial enclosures and test equipment.
- Weight: Weighs around 0.5 kg, which is lightweight and easy to handle during installation and maintenance.
- Mounting Method: Designed for DIN – rail mounting or panel – mounting, providing flexible installation options to suit different system configurations.
- Functional Specifications
- Trigger Modes: Supports various trigger modes, including edge trigger, level trigger, and pattern trigger, allowing precise control over when data acquisition starts. This is useful for capturing specific events or signal characteristics.
- Data Storage: Equipped with on – board memory of 128 MB, which can store acquired data temporarily before it is transferred to a host system. This ensures that no data is lost during high – speed acquisition.
- Communication Interfaces: Features multiple communication interfaces, including USB 3.0, Ethernet, and PCIe, enabling fast and reliable data transfer to a host computer or other system components. The USB 3.0 interface provides a high – speed connection for quick data retrieval, while the Ethernet interface allows for network – based communication and remote access.
- Certification Specifications
- Certifications: Complies with international standards such as CE and FCC, ensuring electromagnetic compatibility and safety. It also meets relevant industrial standards for reliability and performance, making it suitable for use in a wide range of industrial and scientific applications.
