140NOE77101 SCHNEIDER
The 140NOE77101 is a communication module manufactured by Schneider Electric. It is part of the Quantum series of programmable logic controllers (PLCs) and is designed for Ethernet communication in an industrial automation environment.
The 140NOE77101 module provides a high-speed connection to an Ethernet network, allowing the PLC to communicate with other devices, such as human-machine interfaces (HMIs), supervisory control and data acquisition (SCADA) systems, and other intelligent devices. It uses the Modbus/TCP protocol for communication and supports both TCP/IP and UDP/IP communication modes.
The module features dual Ethernet ports for network redundancy and fault-tolerant communication. It also supports various modes of operation, including Ethernet Global Data (EGD) for time-critical applications and I/O scanner mode for distributed I/O control.
The 140NOE77101 module is easy to install and configure, with built-in diagnostics and a web-based configuration tool. It supports advanced features such as network time synchronization, integrated security with user authentication, and remote firmware upgrade capability.
Overall, the 140NOE77101 communication module is a reliable and efficient solution for integrating the Quantum PLC into an Ethernet-based industrial network, enabling seamless communication and control in automation applications.
JD3250F CUTLER HAMMER CIRCUIT BREAKER
D72WN0P76463W98 CUTLER HAMMER MONITOR
NTE1934 ISRA Vision Systems 15″LCD AND PS
1394-SJT10-A ALLEN BRADLEY DIGITAL SERVO CONTROL
6156-AABAAZBBBZ ALLEN BRADLEY IND.WORKSTATION
DR-1030-000 MODICON CYBERLINE 1000A SERVO DRIVE DR10300
TDM2.1-030-300-?W1-000 INDRAMAT
Here are the key parameters and features of the 140NOE77101 module:
- Communication Protocol: TCP/IP
- Ethernet Ports: 2 (One for PLC connection, one for network connection)
- Supported Networks: Ethernet TCP/IP, Modbus TCP/IP
- Communication Speed: 10/100 Mbps
- Maximum Number of Neighbors: 64
- Supported PLCs: Quantum PLCs
- Power Supply: 5V provided by the Quantum PLC backplane
- Operating Temperature: 0 to 60 degrees Celsius
- Dimensions: 119 x 116 x 32 mm
- Weight: 0.3 kg
The 140NOE77101 module offers a reliable and fast Ethernet communication interface for integrating the Quantum PLC system into an Ethernet-based network. It allows for seamless data exchange between the PLC and other devices, facilitating real-time control and monitoring applications.
