140DAI74000 SCHNEIDER
Product Information:
- Brand: Schneider Electric
- Series: Modicon Quantum
- Model: 140DAI74000
- Type: Digital Input Module
- Number of Inputs: 16
- Input Voltage Range: 5-24V DC
- Input Current: 5 mA
- Input Response Time: 5 ms
- Isolated Inputs: Yes
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Dimensions: 4.8 cm x 12.6 cm x 8.2 cm (1.9
The Schneider 140DAI74000 is a digital input module from the Quantum series of programmable automation controllers (PAC) manufactured by Schneider Electric. It is designed to connect various field devices and sensors to a PAC system for monitoring and control purposes.
The module has 16 discrete input channels, which can be used to read digital signals from external devices such as push buttons, limit switches, proximity sensors, or any other devices that produce binary signals. It offers a high level of accuracy and reliability in reading these digital inputs, ensuring that the system receives accurate information for decision-making and automation processes.
The 140DAI74000 module is designed for easy installation onto the PAC system via a backplane connection. It supports a wide range of input voltage levels, allowing it to handle different types of digital signals. It also provides electrical isolation between the input channels and the PAC system, protecting the controller from potential voltage spikes or electrical noise.
The module is compatible with the Unity Pro programming software, which allows users to configure and program the PAC system. It provides diagnostic and status information for each input channel, making it easier for users to troubleshoot and identify any issues within the system.
ASEA BROWN BOVERI YT204001-AA USPP YT204001AA
ABB ASEA BROWN BOVERI YT204001-JN YT204001JN1 REV 3
ASEA BROWN BOVERI 57360001-HG USPP 57360001HG
ASEA BROWN BOVERI 3HAB2236-1 USPP 3HAB22361
ASEA BROWN BOVERI 57777290 USPP 57777290
ASEA BROWN BOVERI 3HAB2242-1 USPP 3HAB22421
ASEA BROWN BOVERI YT213001-AB USPP YT213001AB
The Schneider 140DAI74000 is a digital input module designed to be used with Schneider Quantum PLC systems. It provides 8 digital inputs and operates with a voltage range of 5-60 volts DC or 24 volts AC. The module is equipped with a removable terminal block for easy installation and maintenance. It also features LED indicators to show the status of each input. The 140DAI74000 is designed to be mounted on a DIN rail and can be used in various industrial applications for monitoring and control purposes.
