0399144 SY-0301059F SY-1025115C/SY-1025120E
Product Name
0399144 Industrial Signal Conversion Module
Product Description
The 0399144 is a versatile industrial signal conversion module designed to bridge different signal types in automation systems, enabling seamless communication between sensors, controllers, and actuators with incompatible signal formats. It is widely used in manufacturing, process control, and energy sectors where signal translation is critical for system integration.
In a chemical processing plant, for instance, this module can convert 4-20mA current signals from pressure transducers into 0-10V voltage signals compatible with a legacy PLC, ensuring the control system receives accurate process data. In a factory automation setup, it translates digital pulse signals from encoders into RS-485 protocol data for transmission to a central monitoring system, facilitating real-time speed and position tracking of conveyor belts.
Featuring industrial-grade components, the 0399144 offers high noise immunity and stable performance in environments with electromagnetic interference. Its compact design allows easy installation in control cabinets, while pluggable terminals simplify wiring and maintenance.
Product Parameters
- Input Signal Types: 4-20mA DC, 0-10V DC, 0-5V DC, digital pulses (up to 10kHz)
- Output Signal Types: Selectable via DIP switches: 4-20mA DC, 0-10V DC, 0-5V DC, RS-485 (Modbus RTU)
- Conversion Accuracy: ±0.1% of full scale
- Isolation: 2500V AC galvanic isolation between input, output, and power
- Operating Voltage: 24V DC ±10% (18-30V)
- Power Consumption: ≤3W
- Operating Temperature: -25°C to 70°C
- Response Time: ≤1ms
