Product Description:

The ABB PFEA111-20 is a tension electronics module designed for measuring and monitoring tension in web materials such as paper, film, and textiles in various industrial processes. It is part of ABB’s web tension measurement systems. This module typically connects to two load cells, processes their signals, and provides both voltage and current outputs representing the measured tension. It features adjustable filtering for the output signals and displays tension values.

Key Features:

• Measures and monitors web tension.
• Connects to 2 load cells.
• Provides voltage and current outputs (A+B) with adjustable filtering.
• Displays tension values (A, B, A+B, A-B).
• IP20 rated for protection against dust and water.
• Compact and robust design.
• Multi-language interactive display.
• Selectable tension units on the display (N, kN, kg, lbs, N/m, kN/m, kg/m, pli).
• Maximum load memory and zero offset memory.

Product Parameters:

• Manufacturer: ABB
• Order Number: 3BSE028140R20 (Replaced by 3BSE050090R20 according to some sources)
• Number of Load Cells: 2
• Voltage Output:
  • Range: 0 – 10 V
  • Maximum Load: 5 mA
  • Ripple: <10 mVp-p
  • Wrap Gain: 1
  • Step Response Time: 15 ms
  • Bandwidth: 35 Hz
• Current Output:
  • Range: 4 – 20 mA
  • Maximum Load: 550 Ω
  • Step Response Time: 15 ms
  • Bandwidth: 35 Hz
• Extra Filtering for Voltage and Current Output:
  • Filter Settings ¹ (Cut-off Frequency / Frequencies): 30 ms / 15 Hz, 75 ms / 5 Hz, 250 ms / 1.5 Hz, 750 ms / 0.5 Hz, 1500 ms / 0.25 Hz
    1. www.topbrandsplc.com

    www.topbrandsplc.com
• Wrap Gain Adjustment: 0.5 – 20
• Power Supply: DC 24 V (18 – 36 V)
• Power Requirement: 7.5 W
• Weight: Approximately 0.2 kg to 1 kg (depending on the source and packaging)
• Protection Class: IP20

Specifications:

• Product Type: Tension Electronics Module
• Application: Measuring and monitoring tension in web materials, force measurement, tension control in various industrial processes.
• Display: 2 x 16 character multi-language interactive display.
