NI PXIE-5105

NI PXIE-5105 Module (English Version)

1. Product NameNI PXIe-5105 High-Speed 12-Bit Digitizer Module (PXI Express Oscilloscope Module)
2. Product DescriptionThe NI PXIe-5105 is a high-performance, high-speed digitizer module designed for the PXI Express platform, developed by National Instruments (NI). It is engineered to capture and process fast transient analog signals with high precision, making it ideal for applications such as automated test and measurement, aerospace and defense signal analysis, semiconductor device characterization, and industrial control system monitoring.
   This module integrates a 12-bit analog-to-digital converter (ADC) with a high sampling rate, enabling it to acquire wide-bandwidth signals without significant distortion. It supports both single-ended and differential input configurations, providing flexibility to match different sensor and signal source types. The PXI Express interface ensures high-speed data transfer between the module and the host controller, minimizing latency for real-time signal processing tasks.
   Equipped with built-in signal conditioning features including adjustable input ranges and anti-aliasing filters, the NI PXIe-5105 can adapt to diverse signal amplitudes and frequency ranges. It is fully compatible with NI software suites such as LabVIEW, SignalExpress, and Measurement & Automation Explorer (MAX), allowing users to quickly configure the module, develop custom test routines, and analyze acquired data. Its compact PXI form factor also facilitates integration into multi-module test systems for complex measurement scenarios.
3. Product Parameters
4.

   Parameter	Details
   Manufacturer	National Instruments (NI)
   ADC Resolution	12 bits
   Maximum Sampling Rate	1 GS/s (single-channel), 500 MS/s (dual-channel, interleaved mode)
   Input Bandwidth	DC to 300 MHz
   Input Channels	2 single-ended / 1 differential
   Input Voltage Range	±0.2 V, ±1 V, ±2 V, ±5 V (software-selectable)
   Input Impedance	50 Ω / 1 MΩ (selectable per channel)
   Memory Depth	Up to 256 MSamples per channel
   Triggering Modes	Edge trigger, pulse width trigger, video trigger, external trigger
