Product Name

Vibro – Meter VM600 MPC4 200 – 510 – 070 – 113 Machinery Protection Card

Product Description

MPC4 200-510-070-113

The MPC4 200 – 510 – 070 – 113 is a core component of the VM600 series machinery protection system. It is designed for continuous online monitoring and real – time measurement of machinery health. This card is highly versatile, capable of simultaneously measuring and monitoring four dynamic signal inputs and two speed inputs. The dynamic signal inputs are fully programmable and can accept signals representing acceleration, velocity, and displacement (proximity). With onboard multi – channel processing functions, it can measure various physical parameters, including relative and absolute vibration, Smax, eccentricity, thrust position, casing absolute value and differential expansion, displacement, and dynamic pressure. It features state – of – the – art DSP technology for real – time measurement and monitoring, and offers programmable broadband and narrow – band filters, as well as the ability to simultaneously monitor amplitude and phase. In addition, it has programmable alarm, danger, and determination setpoints, as well as adaptive alarm and danger levels. The front – panel BNC connectors provide convenient access to buffered “raw” sensor signals for analysis. Moreover, the card is hot – swappable, allowing for real – time plug – and – play. It is available in “standard”, “independent circuit”, and “safety” (SIL) versions to meet different application requirements.

Product Parameters12

  1. Dynamic Signal Inputs:
    • Number of Inputs: 4 per MPC4 card.
    • DC Range: 0 to ±20 V.
    • AC Range: Max ±10 V.
    • Common Mode Voltage Range: – 50 to +50 V.
    • CMRR: >60 dB at 50 Hz.
    • Crosstalk: – 72 dB.
    • Input Impedance: 200 kΩ.
  2. Current Input Range:
    • DC Signals: 0 to 25 mA.
    • AC Signals: Max ±8 mA.
  3. Analog Frequency Range:
    • Dynamic Signals: DC to 60 kHz (- 3 dB).
    • AC Signals: 0.1 Hz to 10 kHz without integration, 2.5 Hz to 10 kHz with integration.
  4. Buffered Dynamic Signal Outputs:
    • Output Impedance: 50 Ω.
    • Frequency Range: DC to 10 kHz (- 0.1 dB with load >1 MΩ).
  5. Alarm Processing:
    • Alarm Scanning Interval: Max 100 ms.
    • Alarm Level Value: User – programmable within range.
    • Hysteresis and Latching: User – programmable within range.
  6. Environmental:
    • Operating Temperature: – 25 to 65 °C.
    • Storage Temperature: – 40 to 85 °C.

Product Specifications16

  1. Physical Dimensions:
    • Height: 6U (262 mm, 10.3 inches).
    • Width: 20 mm (0.8 inches).
    • Depth: 187 mm (7.4 inches).
  2. Weight: Approximately 0.40 kg (0.88 lb) or 0.36 kg as per some sources.
  3. Power Supply: AC – input version (115/230 VAC or 220 VDC) and DC – input versions (24 VDC and 110 VDC).
  4. Output Configuration: 2 processed outputs per dynamic channel and 1 processed output per dual – channel (2 per MPC4), 1 processed output per tacho channel.
  5. Communication Interface: RS485 Modbus.
