KUC755AE105 3BHB005243R0105
1. Product Name
KUC755AE105 3BHB005243R0105 is an ABB AC800M Series Analog Input Module (also referred to as ABB 3BHB005243R0105 High-Precision AI Module, Industrial Process Signal Acquisition Module), a core signal processing component designed for ABB AC800M Distributed Control System (DCS) to enable accurate acquisition of industrial analog process signals.
2. Product Description
The KUC755AE105 3BHB005243R0105 module is a high-performance industrial analog input (AI) module developed by ABB, specifically engineered for the AC800M Series DCS. Its primary function is to collect, convert, and transmit analog signals from field sensors (e.g., temperature, pressure, flow, level transducers) to the AC800M controller, providing precise process parameter data for real-time control and monitoring.
Featuring 8 independent isolated input channels, the module supports multiple analog signal types (4-20mA, 0-10V, thermocouple, RTD) with 16-bit resolution, ensuring high measurement accuracy and compatibility with a wide range of industrial sensors. It adopts rugged industrial-grade hardware design with enhanced electromagnetic interference (EMI) resistance and wide environmental adaptability, enabling stable operation in harsh industrial environments (e.g., petrochemical plants, power stations, metallurgical facilities) with temperature fluctuations, vibration, and electrical noise.
Seamlessly integrating with ABB AC800M system components and Control Builder M engineering software, the module supports easy configuration, signal scaling, and fault diagnosis. It is widely used in process industries such as petrochemical, power generation, chemical processing, and water treatment, serving as a critical link between field sensors and the control system to ensure reliable and precise process control.
3. Product Parameters
| Parameter Category | Specific Specifications |
|---|---|
| Product Type | ABB AC800M Series 8-Channel Analog Input Module |
| Manufacturer | ABB |
| Compatible Systems | ABB AC800M Distributed Control System, 800xA Automation Platform |
| Number of Channels | 8 Independent Isolated Input Channels |
| Supported Signal Types | 4-20mA Current Loop, 0-10V DC Voltage, Thermocouple (J/K/T/E/R/S/B/N), RTD (Pt100/Pt1000/Ni100) |
| Measurement Resolution | 16-bit (0.003% Full Scale) |
| Measurement Accuracy | ±0.05% Full Scale (Typical) at 25℃ |
| Input Isolation | Channel-to-Channel: ≥500Vrms; Channel-to-System: ≥1000Vrms |
| Sampling Rate | Up to 10 Samples/Second per Channel (Configurable) |
| Signal Filtering | Configurable Digital Filter (1ms – 100ms) |
| Communication Interface | ABB AC800M Backplane Bus (High-Speed Serial Bus) |
| Power Supply | 24V DC ±10%, Powered by AC800M System Backplane or External Redundant Power Supply |
| Power Consumption | Typical: 6W; Maximum: 10W |
| Operating Temperature | -20℃ to +60℃ (-4°F to +140°F) |
| Storage Temperature | -40℃ to +85℃ (-40°F to +185°F) |
| Relative Humidity | 5% – 95% RH (Non-condensing, IEC 60068-2-3) |
| Protection Class | IP20 (Designed for Cabinet Mounting) |
| Dimensions (W×H×D) | 140mm × 210mm × 80mm (5.51″ × 8.27″ × 3.15″) |
| Weight | Approximately 0.5kg (1.1 lbs) |
| Certifications | CE, UL, CSA, ATEX, IECEx, IEC 61010-1 |
| Diagnostic Capabilities | Channel Open/Short Circuit Detection, Sensor Fault Monitoring, Module Self-Diagnosis |
4. Specifications
(1) Physical Specifications
- Mechanical Design: Modular form factor compatible with ABB AC800M standard mounting racks and TS35 DIN rail, featuring a compact design for space-efficient integration in industrial control cabinets. Reinforced mounting clips ensure stability in high-vibration environments.
- Housing & Material: Flame-retardant industrial-grade plastic shell (UL 94 V-0 rating) with electromagnetic shielding coating, providing mechanical durability and resistance to EMI/RFI interference. The front panel is equipped with dust-proof terminal covers for unused channels.
- Interface & Indicators: Front-panel LED indicators for power status (PWR), module health (OK), and channel fault (per-channel FAULT LEDs); spring-loaded terminal blocks for secure and tool-less wiring, supporting easy connection to field sensors.
(2) Functional Specifications
-
Signal Acquisition Performance
- 8 independent isolated channels support multi-type analog signals, eliminating cross-interference between channels and ensuring signal integrity. Compatible with common industrial sensors (pressure transmitters, temperature RTDs/thermocouples, flow meters) without additional signal converters.
- 16-bit high resolution and ±0.05% measurement accuracy enable precise capture of small signal changes, meeting the requirements of high-precision process control applications.
- Configurable digital filtering (1ms – 100ms) suppresses noise interference from industrial environments, improving signal stability and measurement reliability.
-
System Integration & Configuration
- Seamlessly connects to the AC800M controller via the system backplane bus, enabling high-speed data transmission with low latency (≤10ms).
- Configurable via ABB Control Builder M software, supporting signal type selection, range scaling, filter setting, and fault threshold configuration. The software also provides real-time channel status monitoring and diagnostic data display.
- Supports hot-swappable installation (when used with compatible AC800M racks), allowing module replacement without system shutdown—minimizing maintenance downtime.
-
Reliability & Protection
-
Enhanced electrical isolation (≥500Vrms channel-to-channel) prevents damage to the module and controller from high-voltage surges or sensor wiring faults.- Built-in self-diagnostic functions monitor module hardware, power supply, and channel status (open/short circuits, sensor disconnection), with fault data transmitted to the AC800M controller for alarms and rapid troubleshooting.
- Complies with IEC 61000-4 EMC standards and IEC 61010-1 electrical safety standards, ensuring stable operation in harsh industrial electromagnetic environments and meeting global safety regulatory requirements.
(3) Application Specifications
- Applicable Systems: ABB AC800M Distributed Control System, 800xA Automation Platform, suitable for analog signal acquisition in process control systems.
- Industry Applications: Petrochemical, power generation (thermal, hydro, nuclear), chemical processing, metallurgy, water treatment, pulp & paper, and pharmaceutical industries.
- Typical Use Cases: Process Parameter Monitoring (Temperature/Pressure/Flow/Level), Industrial Sensor Signal Acquisition, High-Precision Process Control, and Factory-Wide Process Data Collection.
