Johnson MS-NAE5510-3

  1. Product NameJohnson Controls Metasys MS – NAE5510 – 3 Network Automation Engine
  2. Product DescriptionThe Johnson MS – NAE5510 – 3 is a core network automation engine of the Metasys series developed by Johnson Controls, specifically designed for the integrated control and intelligent management of large – scale commercial and industrial buildings. It acts as a vital bridge connecting the underlying equipment and the upper – level management platform in building automation systems.
    Equipped with a 133MHz processor, 16GB flash memory and 2GB SDRAM, this module can efficiently process and store data from multiple building subsystems such as HVAC, access control, and lighting, and operate relevant control programs smoothly. It supports mainstream communication protocols in the building automation field, including BACnet IP, Modbus and LonWorks, enabling seamless integration with devices from different manufacturers without additional conversion modules.
    It is furnished with a diverse set of interfaces to meet complex connection requirements, and its hardware design has obtained UL certification. Moreover, it is equipped with an MS – BAT1010 – 0 data protection battery. In case of unexpected power outages, it can prevent the loss of programs and critical data. With excellent environmental adaptability, it can operate stably in harsh environments. It supports both DIN rail mounting and fixed screw mounting, facilitating flexible deployment in various spaces such as standard control rooms and narrow equipment rooms. It is widely used in office buildings, shopping malls, hotels, manufacturing plants and other places to achieve centralized control and energy optimization of building systems.
  3. Product Parameters
    Parameter Category Specific Content
    Electrical Parameters Operating voltage: 24VAC (compatible with 20 – 30VAC); Operating frequency: 50/60Hz; Power consumption: 50VA
    Storage Parameters Flash memory capacity: 16GB; SDRAM capacity: 2GB
    Communication Parameters Supported protocols: BACnet IP, Modbus, LonWorks; Baud rate of LonWork port: 78Kbps; Ethernet port bandwidth: 10/100/1000 Mbps
    Environmental Adaptability Parameters Operating temperature range: -40°C to 85°C; Relative humidity: 5% – 95% (non – condensing)
  4. Product Specifications
  5. Johnson MS-NAE5510-3

    Specification Category Specific Content
    Physical Specifications Dimensions: 22.4cm×39.4cm×27.9cm; Net weight: 2.9kg
    Interface Specifications 1 Gigabit Ethernet port, 1 LonWork port, 2 RS – 485 ports, 2 RS – 232 – C ports, and 2 USB 2.0 ports
    Installation Specifications Supports 35mm DIN rail mounting and fixed screw mounting; Requires horizontal installation
    Certification and Protection Specifications Has UL certification; Equipped with MS – BAT1010 – 0 data protection battery to avoid data loss during power outages
    Functional Parameters Serves as a hub for data transfer in building automation systems; Built – in algorithms to achieve energy optimization of building equipment; Supports centralized control of multiple subsystems such as HVAC, lighting and access control
