IC698PSA100E
-
Product NameGE Fanuc IC698PSA100E RX7i Series PACSystems Power Supply Module
-
Product DescriptionThe IC698PSA100E is a high-reliability power supply module specially developed by GE Fanuc for the RX7i series PACSystems. As a key component to ensure the stable operation of the RX7i platform, it not only provides continuous and stable multi – voltage power output for each module on the backplane but also transmits logic – level sequencing signals to coordinate the operation of the entire system.It is designed to be installed in the leftmost slot (slot 0) of the main rack of the RX7i system, which is convenient for quick assembly and integration. The module has built-in overcurrent, overtemperature, and overvoltage protection mechanisms, which can effectively avoid damage to the module and the connected equipment due to abnormal power supply. It also has a power factor correction function for AC operation, which optimizes power efficiency and reduces energy loss.On the front panel, there is a two-position on-off switch and LED status indicators. The switch can turn on or off the output channel without interrupting the AC input, and the indicators can intuitively display the field and output status, facilitating on-site personnel to monitor and troubleshoot. It is widely used in various industrial automation scenarios such as manufacturing production lines and energy management systems, providing a reliable power guarantee for the stable operation of the RX7i series control system.
-
Product Parameters
Parameter Item Details Input Voltage Range 85 – 264 VAC (47 – 63 Hz); 100 – 150 VDC Nominal Rated Voltage 120/240 VAC or 125 VDC Input Power Typical 125 watts; Maximum 150 watts Total Output Power 100 watts (without forced air cooling at 0 – 60℃) Output Voltage & Current +5 VDC (0 – 20 A); +12 VDC (0 – 2 A); -12 VDC (0 – 1 A) Isolation Voltage 1500 volts Power Factor Minimum 0.99 Holdup Time 5 milliseconds Ride Through 15 milliseconds
