1. Product NameGE Fanuc IC697PWR724 90-Watt 24VDC Power Supply Module
2. Product DescriptionThe IC697PWR724 is a dedicated power supply module tailored for the GE Fanuc Series 90 – 70 PLC systems, with a maximum output power of 90 watts and a nominal input voltage of 24VDC. It is a critical component for ensuring stable and continuous operation of industrial automation control systems.
   This module is installed in the leftmost slot of the rack via a slide – in mounting method and connects to the rack through a 48-pin backplane-mounted connector. It not only works for single-rack applications but can also supply power to a second rack by using the IC697CBL700 prewired interconnect cable, provided the total load does not exceed its rated power. It outputs three voltage levels (+5VDC, +12VDC, -12VDC) and delivers logic – level sequencing signals to the backplane to coordinate the operation of the entire PLC system.
   It is equipped with multiple protection functions such as electronic overcurrent and overvoltage protection, and the 5 – volt bus is also furnished with short – circuit protection, which can promptly respond to abnormal conditions like short circuits and overloads to avoid damage to the module and the connected equipment. Additionally, it has a power ride – through capability, which can maintain normal output for 10 milliseconds even when the input power is completely lost under full – load conditions, effectively preventing system downtime caused by momentary power outages. When the ambient temperature exceeds 50°C, the maximum output power of the module needs to be derated to ensure operational reliability.
3. Product Parameters

   Parameter Item	Details
   Nominal Input Voltage	24VDC
   Input Voltage Range	18 – 32VDC
   Maximum Input Power	160W (at full load)
   Maximum Input Inrush Energy	22 Joules
   Maximum Total Output Power	90W
   Output Voltage Ranges	+5VDC (4.90 – 5.25V, nominal 5.07V); +12VDC (11.75 – 12.6V); -12VDC (-12.6 to -11.75V)
   Output Current Capacity	+5VDC: Up to 18A; +12VDC: Up to 1.5A; -12VDC: Up to 1A
   Power Ride – through Time	10ms (for total loss of input power at full load)
   Operating Temperature Range	0 – 60°C (derating required above 50°C)

4. Specifications
5.

   Specification Item	Details
   Manufacturer	GE Fanuc (Emerson)
   Product Category	Industrial PLC Power Supply Module
   Product Series	Series 90 – 70
   Weight	2.50 lbs (approximately 1.13 kg); some sources record 2000g due to packaging differences
   Mounting Method	Slide – in rack mounting, installed in the leftmost
