GE IS420PUAAH1A
| Product Name | GE IS420PUAAH1A Universal Input/Output Module (for Mark VIe Series Control System) |
| Product Description | The GE IS420PUAAH1A is a highly integrated and flexible universal input/output module specifically developed for GE’s Mark VIe series control systems. It serves as a critical component in industrial automation, widely applied in power generation, petrochemical, metallurgy, and water treatment industries. This module is capable of collecting various on-site analog signals such as temperature and pressure, converting them into digital signals for the control system to process, and outputting control signals to drive field actuators. It features independently routable wiring sections that reduce panel space usage and facilitate channel – by – channel debugging. With functions like hot – swapping and automatic reconfiguration, it minimizes system downtime during maintenance. It seamlessly integrates with ControlST V7.02.00C and higher software versions, and its robust industrial – grade design enables stable operation in harsh field environments, providing reliable data acquisition and control support for large – scale industrial control systems. |
| Product Parameters | 1. Channel Parameters: Equipped with 16 simplex analog channels, which can be flexibly configured for thermocouple input/output, RTD input/output, voltage input, 4 – 20mA current input/output, pulse accumulator, and digital input.
2. Precision & Scanning Parameters: The measurement accuracy is better than 0.1% within the specified temperature range; the scanning time is 5ms, and the frame rate can reach 10ms, ensuring real – time data collection and processing.
3. Power Supply Parameter: Adopts a 24V DC power supply, which is compatible with the power supply system of the Mark VIe series control chassis. 4. Environmental Adaptability Parameters: The operating temperature range is -40°C to 70°C; the relative humidity tolerance is 5% – 95% (non – condensing), enabling it to adapt to the temperature and humidity fluctuations of most industrial sites. |
| Specifications | 1. Physical Specifications: The typical dimensions are 6.2 inches × 4.3 inches × 1.5 inches (length × width × height), and the net weight is approximately 0.45kg, which is compact and convenient for installation in control cabinets.
2. Installation & Compatibility Specifications: It supports DIN rail mounting for quick deployment. It is fully compatible with GE’s Mark VIe series control systems and works with ControlST V7.02.00C and later software versions. It can also be expanded with other GE I/O modules like the IS200 and IS400 series. 3. Protection Specifications: It has an IP67 protection rating, which is dustproof and waterproof, suitable for harsh industrial environments with potential moisture or dust. It also has built – in overvoltage and overcurrent protection to prevent module damage caused by abnormal circuit conditions. 4. Functional Specifications: Supports hot – swapping and automatic reconfiguration. It is compatible with communication protocols such as Modbus and Profibus, enabling seamless data interaction with the upper – level control system and ensuring the stable operation of the entire industrial control network. |
