EMERSON A6370D 9199-00040
- Product Name
Emerson EPRO A6370D Overspeed Protection Monitor
- Product Description
The Emerson EPRO A6370D is a key component of the AMS 6300 SIS overspeed protection system. It is specifically designed to reliably protect industrial machinery by continuously monitoring rotational speed and promptly triggering safety measures once overspeed occurs. This module is engineered to be mounted in a 19-inch rack with 84 HP width and 3 RU height, working in conjunction with the A6371 system backplane. A complete AMS 6300 SIS is composed of three A6370 protection monitors and one A6371 backplane.
It supports a variety of sensors such as eddy current, Hall element, and magnetic (VR) sensors, and is equipped with multiple communication interfaces including USB, RS – 485, and Profibus DP. These features enable seamless integration with various industrial control systems. It is widely used in turbines of chemical plants, pumps on oil platforms, and test engines in the aerospace field to ensure operational safety and prevent equipment damage caused by excessive speed.3. Product Parameters
| Parameter Categories | Specific Parameters |
|---|---|
| Sensor Power Supply | Nominal supply voltage: -24.5V ± 1.5V DC (short – circuit proof, galvanically separated); Maximum current: 35mA |
| Signal Input (Eddy Current & Hall Element Sensors) | Voltage range: 0V to 26V (+/-), protected against reverse polarity; Limit range: ±48V; Frequency range: 0 to 20kHz; Input resistance: 100kΩ (typical) |
| Signal Input (Magnetic VR Sensors) | Minimum voltage: 1Vpp; Maximum voltage: 30Vrms; Frequency range: 0 to 20kHz; Input resistance: 18kΩ (typical) |
| Digital Inputs (Backplane) | Quantity: 4 (galvanically separated with common ground); Logic low level: 0V to 5V; Logic high level: 13V to 31V (open); Input resistance: 6.8kΩ (typical) |
| Current Outputs (Backplane) | Quantity: 2 (electrically isolated); Range: 0/4 to 20mA or 20 to 4/0mA; Accuracy: ±1% of full scale; Maximum load: <500Ω; Maximum output current: 20mA |
| Digital Outputs (Backplane) | Quantity: 7 (short – circuit proof); Logic low level: <100mV; Logic high level: -2V; Maximum current: 25mA |
| Pulse Outputs (Backplane) | Quantity: 3 (open – collector – emitter, current limited); Maximum voltage: 31.2V; Maximum current: 16mA @24V; Frequency range: 0 to 20kHz |
| Pulse Output (Front Panel) | Voltage: 0 to 5V TTL signal; Frequency range: 0 to 20kHz; Output impedance: 10kΩ (typical) |
| Sensitivity Output (Front Panel) | Voltage: 0 to 3.9V; Factor: 0.15 ±3%; Frequency range: 0 to 20kHz; Output impedance: 10kΩ (typical) |
| Communication | USB (Type B, configuration interface); RS – 485 (supports up to 32 devices, baud rate: 38400, 57600, 115200 baud); Profibus DP (for A6370D/DP model, supports up to 31 devices, data transmission rate up to 12Mbit/s) |
| Reaction Time | < Measuring time + 8ms; At 3000r/min: 35ms in “1x per revolution” mode, 12.5ms in automatic mode; Rotational direction response time: < 3 * period time of input signal + 8ms |
Specifications
Specification Items Details Physical Specifications Weight: 490g; Installation size: Fits 19-inch racks (84 HP width, 3 RU height); Dimensions: 211×130×43mm (alternative size: 19cm×12cm×7.6cm) Environmental Specifications Operating temperature: -20°C to +65°C; Storage temperature: -40°C to +70°C; Relative humidity: 5% – 95% (non – condensing); Vibration resistance: 0.15mm, 20m/s², 58 – 62Hz to 150Hz (compliant with IEC 60068 – 2 – 6); Shock resistance: 100m/s², 6ms AC; Protection rating: IP20 Other Specifications Certifications: CE, ISO 9001 certified; Short – circuit proof design for multiple outputs; No user – serviceable parts, no calibration required
