1. Product DescriptionThe FOXBORO RH924WA is a multi-functional high-performance module integrated into the FCP280 series, serving dual core roles as a field control processor and a fiber optic network adapter for industrial automation scenarios. It is specifically designed to meet the demands of harsh industrial environments, functioning as a critical link for data transmission and equipment control in FOXBORO’s I/A series DCS systems.
   As a field control processor, it is equipped with a powerful ARM Cortex A15 processor and sufficient memory capacity, enabling it to efficiently handle complex control tasks and support connection with a large number of I/O modules. It also integrates multiple input and output functions, supporting both voltage and current signal types with high measurement accuracy to ensure reliable control of on-site devices. As a fiber optic network adapter, it features a built-in fiber optic network interface, supporting high-speed data transmission up to 4 Gbps and enabling long-distance communication with other controllers.
   The module supports multiple communication protocols such as Modbus, Profibus, and HART, facilitating seamless integration with various industrial devices and systems. It adopts a modular design for easy installation and maintenance, and is furnished with comprehensive protection mechanisms to resist external interference, ensuring stable and continuous operation in industries like oil and gas, chemical engineering, and power generation.
2. Product Parameters

   Parameter Category	Specific Content
   Core Performance Parameters	Processor: ARM Cortex A15; Memory: 2 GB RAM, 4 GB flash; Maximum supported I/O modules: Up to 2048
   Power Supply Parameter	Input voltage: 24 V DC
   Communication Parameters	Supported protocols: Ethernet, Modbus, Profibus, HART, fiber optic; Data transmission rate: Up to 4 Gbps; Fiber compatibility: Single-mode and multimode fibers
   I/O Parameters	Input types: Voltage input, current input; Output types: Voltage output, current output; I/O accuracy: ±0.1%
   Environmental Adaptability Parameters	Operating temperature: -40°C to +70°C; Storage temperature: -55°C to 105°C; Relative humidity: 5% – 95% (non-condensing)

3. Product Specifications

   Specification Category	Specific Content
   Physical Specifications	Dimensions: 220 mm × 105 mm × 60 mm; Net weight: Approximately 2.5 kg (varies slightly by configuration); Packaging dimensions: 17.8 cm × 20.0 cm × 5.8 cm
   Fiber Optic Interface Specifications	Connector types: SC or LC; Communication distance: Up to 2 km (single-mode fiber), up to 500 m (multimode fiber)
   Quality & Warranty Specifications	Origin: USA; Condition: Brand-new original; Warranty period: 12 months
   Installation & Configuration Specifications	Modular structure for easy customization and expansion; Compatible with FOXBORO I/A series DCS systems for seamless integration and straightforward installation
