BEIJER 04380A
-
Product NameBeijer 04380A E300 Series Industrial HMI Operator Interface Terminal
-
Product DescriptionThe Beijer 04380A is a dedicated industrial HMI operator interface terminal under Beijer’s E300 series, which is developed to realize intuitive and reliable human-machine interaction in various industrial scenarios. It serves as a bridge between on-site industrial equipment and operators, enabling convenient monitoring of equipment operating status and simple control operations.This terminal is powered by 24VDC and is compatible with a certain voltage fluctuation range, adapting to the unstable power supply environment of industrial sites. It is equipped with a backlit monochrome LCD display, which ensures clear readability even in low-light or strong-light working conditions. It is also configured with user-assignable function keys and dual-color LED indicators, allowing users to customize operation functions according to actual application needs and quickly obtain equipment status signals.With built-in expandable flash – RAM and standard communication interfaces such as RS232C/RS422, it can smoothly communicate with mainstream industrial controllers like PLCs, realizing efficient data transmission. In addition, it meets the Class I, Div 2 hazardous location standards, making it applicable to harsh industrial environments such as marine equipment and chemical plants. It is widely used in equipment control and production process monitoring in fields like manufacturing, marine engineering, and petrochemical industry.
-
Product Parameters
Parameter Category Specific Content Electrical Parameters Power supply: 24VDC (20 – 30VDC); Power consumption: 350mA or 450mA (varies with working conditions); Powered by Class 2 power supply Display Parameters Display type: Backlit monochrome LCD; Display resolution: 240 × 64 pixels; Text display: 4 (8) lines × 20 (40) characters; Display size: 127.2 × 33.9mm Memory Parameters Memory type: Flash – RAM; Base memory capacity: 400KB; Expandable memory range: Up to 4 – 8MB Communication Parameters Supported interfaces: RS232C, RS422; Interface slots for expansion cards: 1 Functional Component Parameters LED indicators: 16 (red and green dual – color); Function keys: 8 (user – assignable) -
Product Specifications
-
Specification Category Specific Content Physical Specifications Net weight: 1.35kg; External packaging dimensions (approximate): 12 × 12 × 6 inches (for transportation reference) Environmental Adaptability Specifications Hazardous location rating: Class I, Div 2, Groups A – D, T4; Suitable for harsh industrial environments including marine and chemical hazardous areas Compatibility Specifications Compatible with mainstream industrial controllers such as PLCs; Supports connection with industrial equipment through RS232C/RS422 communication protocols Functional Specifications Supports customized function key settings for matching different industrial control logic; Equipped with expansion card slots to meet personalized functional expansion needs; Has stable data interaction capabilities to realize real – time synchronization of equipment operation data and operator instructions Quality & Origin Specifications Manufactured in Sweden; Provided with commercial warranty services (varies by supplier, e.g., 2 – year warranty or 30 – day satisfaction guarantee)
