ABB S-073N 3BHB009884R0021

  1. Product NameABB S – 073N 3BHB009884R0021 Phase Module for ACS6000 Medium – Voltage AC Drive
  2. Product DescriptionThe ABB S – 073N 3BHB009884R0021 is a dedicated three – phase module customized for the ABB ACS6000 medium – voltage AC drive system. As a core power conversion component of the drive system, it undertakes the key task of converting input AC power into DC power for the inverter unit, and then the inverter further converts the DC power into AC power with adjustable frequency and voltage to precisely control the speed and torque of high – power industrial motors.
  3. ABB S-073N 3BHB009884R0021
This module integrates advanced power semiconductor components and sophisticated drive and protection circuits. It can effectively shield the ACS6000 drive system from overcurrent and overvoltage hazards, ensuring stable and reliable operation under high – load industrial conditions. It is mainly used in industrial scenarios that require driving large – scale equipment with power up to 500kW, such as metallurgy, mining, and power generation. Although it has been discontinued by ABB, it is still widely used in the maintenance and operation of existing ACS6000 drive systems and can be obtained through professional industrial parts distributors.
  1. Product Parameters| Parameter Categories | Specific Parameters || —- | —- || Electrical Performance | Rated voltage: 380 – 500V AC; Rated current: 300A; Maximum matching drive power: 500kW || Core Functional Parameters | Power conversion type: Three – phase AC to DC; Response time of overcurrent/overvoltage protection: <20μs || Power Semiconductor | Equipped with integrated gate – commutated thyristors (IGCT) for low on – state loss and fast switching performance || Compatibility | Fully compatible with ABB ACS6000 series medium – voltage AC drive systems; Supports parallel operation with same – type modules for power expansion |
  2. Specifications| Specification Items | Details || —- | —- || Physical Specifications | Weight: 175kg; Country of origin: Poland; Mounting method: Standard cabinet – type modular installation, compatible with ACS6000 drive cabinet mounting holes || Cooling Specifications | Cooling method: Compatible with forced air cooling or liquid cooling systems of ACS6000 drive systems; Operating ambient temperature: -20°C to +70°C || Environmental Adaptability
