ABB PPD113-B03-10-150000
ABB PPD113-B03-10-150000 High-Speed Controller Module (AC 800PEC Series, Power Electronic Control) ⚡
Product Description
The ABB PPD113-B03-10-150000 is a high-performance CPU/controller module belonging to the AC 800PEC (Power Electronic Control) platform, tailored for demanding power electronics applications such as medium/high-voltage drives, converters, STATCOMs, and series voltage restorers. It features a high-clock RISC processor with 64-bit FPU, enabling ultra-fast cycle times (down to ~25–100 µs) for precise closed-loop control and real-time signal processing. The module integrates dual Ethernet ports, CEX2-Bus (RS422), and Anybus/Modbus TCP slots for seamless connectivity to I/O modules, gate drivers, and substation automation systems. Designed for harsh industrial environments with extended temperature ranges and robust EMC protection, it ensures reliable operation in critical power conversion and utility applications.
Product Parameters
| Parameter Category | Specific Parameter |
|---|---|
| Model/Ordering Code | PPD113-B03-10-150000; Typical Internal ID: 3BHE023584 Series (e.g., 3BHE023584R2060/R2530) |
| Platform | AC 800PEC (Power Electronic Control) |
| Processor & FPU | Industrial RISC CPU (~600/750 MHz), 64-bit Floating-Point Unit (FPU) |
| Memory (Typical) | 64 MB ECC RAM (error-correction) |
| Cycle Time | Down to ~25–100 µs (high-speed control loops); configurable for mixed fast/slow tasks |
| Auxiliary Supply (Typical) | 24 V DC (19.2–30 V DC); check variant for 110/220 V DC/AC options |
| Communication Interfaces | 2× 10/100BASE-TX Ethernet; CEX2-Bus (RS422); Anybus/Modbus TCP slots (U4/U5) |
| Operating Temperature (Ambient) | -40 °C to +70 °C (standard) |
| Storage Temperature | -40 °C to +85 °C |
| Protection Class | IP20 (module); system-level IP per enclosure |
| Compliance | IEC 61131-3 (programming), IEC 61000-6-2/4 (EMC), relevant power electronics safety standards |
Specifications
Mechanical Specifications
- Dimensions (Typical, Rack Mount): ~450 mm (H) × 100 mm (W) × 145 mm (D) (confirm with unit/datasheet)
- Weight: ~2.59 kg (approximate, incl. base and connectors)
- Mounting: Rack-mounted in AC 800PEC chassis; torque-controlled fasteners
- Housing: Flame-retardant plastic (UL94 V-0)+metal shielding for EMC
- Terminals/Connectors: Screw/clamp terminals for power/CEX2-Bus; RJ45 for Ethernet; Slot-based
