Product Name
ABB 5SHX1445H0001 IGCT Power Module with 3BHL000391P0101 Gate Drive Board, 3BHB003230R0101 Control Board & 5SXE05-0152 Interface/Driver (MV Drive/Converter Assembly, ACS1000 Series Compatible).
Product Description
The 5SHX1445H0001 is a high-power Integrated Gate-Commutated Thyristor (IGCT) module, the core power switching element for medium-voltage drives (e.g., ACS1000), traction converters, and grid-tied inverters. It is paired with the 3BHL000391P0101 gate drive board to provide precise turn-on/turn-off control, overcurrent/short-circuit protection, and thermal monitoring. The 3BHB003230R0101 serves as an auxiliary control board for interlocks, status feedback, and system-level coordination, while the 5SXE05-0152 is an interface/driver component enabling signal conditioning and communication between the gate drive and main controller. Together, they form a rugged, high-reliability power stage for high-voltage, high-current applications such as large motor variable-speed drives, renewable energy grid integration, and industrial traction systems. Key attributes include low switching losses, fast commutation, and built-in protection to ensure safe operation under transient conditions.
Key Parameters & Specifications (Consolidated & Annotated)
| Category | Specification | Notes (Disclaimer/Discrepancy Alert) |
|---|---|---|
| Manufacturer | ABB | Power electronics/MV drive components, not PLC/DCS I/O |
| Primary Part No. | 5SHX1445H0001 (IGCT power module); 3BHL000391P0101 (gate drive); 3BHB003230R0101 (control board); 5SXE05-0152 (interface/driver) | Confirm revision on unit label |
| Product Type | IGCT power module+gate drive/control/interface assembly | For MV drives (ACS1000 typical) |
| 5SHX1445H0001 IGCT Ratings (Typical/Series Common) | Blocking voltage (V_CEO): ~4.5 kV; RMS current (I_RMS): ~1445 A (series naming convention); Junction temp (T_j): -40 °C to +150 °C (max); Switching freq: Up to ~10 kHz (application-dependent) |
